CADDY® Conduit Hangers from Flange, Wire or Rod

CADDY® Conduit Hangers from Flange, Wire or RodPrint this page

ERICO offers CADDY Conduit Hangers from Flange, Wire or Rod.

Features

  • Conduit support to rods or flanges
  • Can be used for flexible metallic tubing, armored cable, portable cables, control tubes, communications cable, etc.
  • No installation tools required

NOTE: May require dedicated drop wire/rod and EC311 – consult local authority

Applications

Supports conduit (EMT, Rigid, ENT, MC/AC and Aluminum) to rods (horizonal application only) or flanges.

More Information

Conduit hangers

Conduit hanger from flanger, wire or rod photo

Fig 1 - Load 100 lbs
Fig 2 - Load 50 lbs

Conduit #10 & #12 Wire #8 & #9 Wire 3/16" & 1/4" Rod 1/8"-1/4" Flange 5/16"-3/8" Flange 7/16"-1/2" Flange
1/2" EMT K8 K8 K8 K8 K12 K12
1/2" Rigid K8 K12 K12 K12 K12 K16
3/4" EMT K12 K12 K12 K12 K16 K16
3/4" Rigid K12 K12 K16 K16 K20* K20*
1" EMT — K16 K16 K16 K20* K20*
1" Rigid — — — K20* K20* K20*
1-1/4" EMT — K20 K20 K20 — —
* For horizontal application only
"K" Series packaged 100 per box

  Wire Sizes
Cable Size #12 #10, #9, #8 Std Box Qty
14-2 (.433-.475 O.D.) KX KX 100
4-3 (.453-.500 O.D.) KX KX 100
12-2 (.467-.510 O.D.) KX KX 100
12-3 (.489-.535 O.D.) KX K8 100

Due to a policy of continued product development, specifications are subject to change without notice.
