CADDY® ROD LOCK Anchor Screw

CADDY® ROD LOCK Anchor ScrewPrint this page

CADDY® ROD LOCK is an innovative mounting system that simplifies the installation of threaded rod. The system includes the CADDY ROD LOCK beam clamp, channel nut and an anchor screw. The CADDY ROD LOCK system features a breakthrough "push-install" design - simply push the threaded rod through the mounting hole and it instantly locks into position.

The CADDY ROD LOCK anchor screw helps to reduce the installation time of threaded rod by up to 35% when installing electrical and mechanical systems. It can be used on threaded rod with slightly damaged threads and minor burrs, helping to save time by minimizing the amount of deburring that is usually required prior to installation.

The anchor screw has a load capacity up to 660 lbs (3/8" rod) or 2900 N (M8, M10 rod) and features an electro-galvanized finish for superior corrosion protection.

Features

Anchor Screw
  • Works with slightly damaged threads and minor burrs on the threaded rod
  • Reduces installation time up to 35%
  • Load capacity up to 660 lbs (3/8" rod) or 2900 N (M8, M10 rod)
  • FM® Approved (390010, CRLA37EG)
  • Electro-galvanized finish
  • 3:1 Safety Factor
FM is a registered certification mark of FM Approvals LLC, LTD.


Approval Certificate

Applications

The CADDY® ROD LOCK anchor screw helps to reduce the installation time of threaded rod by up to 35% when installing electrical and mechanical systems. It can be used on threaded rod with slightly damaged threads and minor burrs, helping to save time by minimizing the amount of deburring that is usually required prior to installation.

More Information



Part
Number
Description Rod
Size
Ø
A B C Static
Load
(N1)
Socket
Size
Drill
Hole
Depth
Drill
Bit
Size
Standard
Packaging
Quantity
CRLA37EG
3/8" CADDY® ROD
LOCK Anchor Screw
3/8"
2.85"
1.26"
.87" 660 lbs
7/8" 2" 5/16" 25
390009
CRLAM8EG
M8
72.0 mm
32.0 mm
22.0 mm
2900 N
22 mm
50 mm
8 mm
25
390010
CRLAM10EG
M10
72.0 mm
32.0 mm
22.0 mm
2900 N
22 mm
50 mm
8 mm
25

For use on plain and electro-galvanized (EG) hardware only
Tested in 3000 psi (20.67 Mpa) concrete


Click to play this video
CADDY® ROD LOCK Informational Video Duration: 2m 52s

Downloads

Due to a policy of continued product development, specifications are subject to change without notice.
